Filters



EVTN offers a line of filters that serves a host of industries, such as Oilfield, Chemical, Electronic, Pharmaceutical and Food and Beverage. In addition, these products can be used for air purification in museums, archives and paper processing. EVTN develops and manufactures complete turnkey systems to solve any specialized separation and purification requirements.




oil block obsorption cartridge

OILBLOCK OS605 Cartridge.


The Oil Block absorption cartridges are specifically designed and manufactured for the high efficiency removal of free dispersed oils from water.  The cartridges are being successfully applied in the oil and gas industry, bilge water treatment systems, contaminated surface water run-off and other industrial process applications.  The OilBlock absorption cartridge is filled with a unique co-polymer.  This element absorbs the hydrocarbons very fast and actually molecularly bonds the oil.  The water flows radially into the cartridge and the absorption media immediately encapsulates the oil and in time solidifies.  The OilBlock cartridge will fit into Twin Filter standard cartridge filter units.



OS605 Cartridge above more specifications here.




OS507 Dynamic Centrifugal

DYNAMIC CENTRIFUGAL COALESCER


The dynamic centrifugal coalescer increases the performance of produced water separation systems.  Its effect is a combination of centrifugal force and a coalescer.  An element (core) consisting of thousands of tubes (pore size 0.4 - 1.4mm) is rotated.  The multi-phase liquid with different mass-densities passes through the core.  Because of the centrifugal force, the droplets of the discontinuous phase coalesce on the walls of the tubes.  Oil droplets >5 micron increase up to 200 micron.  The DCC is a non-plugging coalescing technology and a proven solution for increasing the performance of produced water treatment systems.


OS507 Dynamic Centrifugal above more specifications here.




Twin Filter OilClog™ absorption Cartridges

OILCLOG OS606


The Oil Clog absorption cartridges are effective in various water treatment applications but have been specifically designed and manufactured for produced water treatment at oil and gas production facilities.  They successfully remove free and dissolved hydrocarbons (TPH) and emulsified oils from water with great efficiency.  The Oilclog™ cartridges are being successfully applied in the oil and gas industry, bilge water treatment systems, contaminated surface water run-off and other industrial process applications.  The Oilclog absorption cartridge is filled with granulated organic material, impregnated with a powerful surfactant.  This element absorbs the hydrocarbons very quickly and bonds with the oil.  The water flows from top to bottom through the cartridge and the absorption media immediately reacts with the hydrocarbons.  The OilClog™ cartridge will fit into standard Twin Filter cartridge filter units.


OS606 Oil Clog absorption cartridges above more specifications here




OS206 Single Vessel Filters

SINGLE VESSELS

We offer a standard 6 bar, stainless steel design, or custom made to suit your needs. Being the manufacturer of both vessels and consumables, Twin Filter can offer the optimum combination.

APPLICATIONS: In general, solid / fluid fil tration, such as: Amine filtration, Glycol filtration, Pre-filtration of RO Completion fluids, Water injection, Produced water, Seawater intake, Oily water clean up, Diesel filtration.



OS206 Single Filter Vessels above more specifications here
